The process of prototype PCB manufacturing begins with the design phase, where a schematic of the circuit is translated into a PCB layout using specialized software like Eagle, Altium Designer, or KiCad. Once the design is complete, it is converted into a set of files that define the board’s physical characteristics, such as traces, vias, and component placements. Prototype PCBs are typically produced in small batches (often between 1-10 units), allowing for quick iteration and testing.
